CLASS 1000 METER
29
62-0388-01
Altitude
2000 Meters Maximum
Voltage Overload
+25% Continuously: +100% For 20 Cycles
Current Sensor
Overload
100% For 1 Minute Without Damaging Meter
Pollution Degree
Degree 2 In Accordance With IEC 664
Installation
(Overvoltage)
Category
Category 3
Measurement
Category
Category 3
Enclosure Material
Indoor Housing Rating (Standard): UL Type 1
Outdoor Housing Rating (Optional): NEMA 4X
Display Readout
KWh Accumulated, Instantaneous kW
Standard Ranges
3-wire 115/208 Vac; 25,50,100, 200
2 Phase 120/240 Vac; 25,50,100, 200, 400
IDR Interface Port
Cable Specification: UL-listed/rated
Telephone
Cord. 6 conductor.
Input/output Voltage:
+5 VDC/18 VAC
Cable Connector:
RJ-45 male IDC
Circuit Input Isolation:
5.3kVAC for one minute
Circuit output Isolation:
2.5kVAC
Isolated Pulse/Alarm
Outputs
Output Voltage Potential:
0 VDC to +5 VDC Logic Levels
Mating Plug Connector:
Weidmuller PN: 152876
Signal Isolation Voltage:
5.3K VAC for 1 Minute
Recommended
In-line Fuse
Manufacturer: Littlefuse
Mfg. Part No.:
KLDR.100
Rating:
100mA, Time-delay, 600VAC
Cartridge Fuse
