1-10 Part II

1 Operational Theory

Model 6000B

Teledyne Analytical Instruments

Photodetector and Preamplifier PCB

1.7

Sample Systems

Below are sample systems that deliver gases to the 6000/6020 sample

cell of the Analysis Unit. Depending on the mode of operation either
sample or calibration gas is delivered.

Detector

Chopper Motor

Span/Zero Flag

and Solenoid

M/R Filter Wheel
