3 Operation

Model 6000

3-28 Part I

Teledyne Analytical Instruments

3.8

Programming

CAUTION: The programming functions of the Set Range and

Curve Algorithm screens are configured at the facto-
ry to the users application specification. These func-
tions should only be reprogrammed by trained,
qualified personnel.

To program, you must:

1. Enter the password, if you are using the analyzer’s password

protection capability.

2. Connect a computer or computer terminal capable of sending an

RS-232 signal to the analyzer RS-232 connector. (See chapter 2
Installation for details). Send the rp command to the analyzer.

3. Press the

System

button to start the

System

function.

DIG_FILT SELF-TEST

PWD LOGOUT MORE

Use the < > arrow keys to blink MORE, then press

Enter

.

AUTOCAL FILSOLL HOLD

CAL-HOLD-TIMER MORE

Select MORE and press ENTER one more time

ALGORITHM

APPLICATION

MORE OUTPUT: 4MA

Now you will be able to select the APPLICATION and ALGORITHM

set-up functions.

3.8.1 The Set Range Screen

The Set Range screen allows reprogramming of the three analysis ranges

and the calibration range (background gas, low end of range, high end of range,
and % or ppm units). Original programming is usually done at the factory ac-
cording to the customer’s application. It must be done through the RS-232 port
using a computer running a terminal emulation program.

Note: It is important to distinguish between this System program-

ming subfunction and the Range button function, which is an
operator control. The Set Range Screen of the System func-
tion allows the user to DEFINE the upper and lower limits of a
range AND the application of the range. The Range button
