Photometric Analyzer

Operation 3

Part I 3-17

Teledyne Analytical Instruments

####.## % SO2

4 Left=#.### S—Zero

The zeroing process will automatically conclude when the output is within

the acceptable range for a good zero. Then the analyzer automatically returns to
the

Analyze

mode.

3.4.1.2

Manual Mode Zeroing

Press

Zero

to enter the

Zero

function. The screen that appears allows you

to select between automatic or manual zero calibration. Use the

∆∇ keys to

toggle between

AUTO and MAN zero settling. Stop when MANUAL appears,

blinking, on the display.

Select zero

mode: MANUAL

Press

Enter

to begin the zero calibration. After a few seconds the first of

three zeroing screens appears. The number in the upper left hand corner is the
first-stage zero offset. The microprocessor samples the output at a predeter-
mined rate.

####.## % SO2

Zero adj:2048 C—Zero

The analyzer goes through C–Zero, F–Zero, and S–Zero. During C–Zero

and F–Zero, use the

∆∆∆∆∆∇ keys to adjust displayed Zero adj: value as close as

possible to zero. Then, press

Enter

.

S–Zero starts. During S–Zero, the Microcontroller takes control as in Auto

Mode Zeroing, above. It calculates the differences between successive sam-
plings and displays the rate of change as

Slope= a value in parts per million per

second (ppm/s).

####.## % SO2

Slope=#.### S—Zero

Generally, you have a good zero when

Slope is less than 0.05 ppm/s for

about 30 seconds.

Once zero settling completes, the information is stored in the analyzer’s

memory, and the instrument automatically returns to the

Analyze

mode.
