Photometric Analyzer

Part I: Control Unit

Part I: 2-9

Teledyne Analytical Instruments

RD

2

Received Data

TD

3

Transmitted Data

DTR

4

Data Terminal Ready

COM

5

Common

DSR

6

Data Set Ready

RTS

7

Request to Send

CTS

8

Clear to Send

RI

9

Ring Indicator

The data sent is status information, in digital form, updated every two

seconds. Status is reported in the following order:

The concentration in percent

The range is use (HI< MED< LO)

The span of the range 0-100%, etc)

Which alarm - if any - are disabled (AL-x DISABLED)

Which alarms - if any - are tripped (AL-x ON)

Each status output is followed by a carriage return and line feed.

Three input functions using RS-232 have been implemented to date.

They are described in Table 2-4.

Table 2-4: Commands via RS-232 Input

Command

Description

as

Immediately starts an autospan.

az

Immediately starts an autozero.

st

Toggling input. Stops/Starts any status message output
from the RS-232, Until st is sent again.

The RS-232 protocol allows some flexibility in its implementation.

Table 2-5 lists certain RS-232 values that are required by the 6000A.
