Operation Model 3110
Teledyne Analytical Instruments 18
3.2.2 HOME Screen
The HOME screen displays the oxygen concentration at the level of
the current range (ppm or %). The concentration is shown in the upper
line the current range is indicated on the second line.
Note: In almost all available screens, the first line displays the
oxygen concentration.
3.2.3 DATE Screen
Use the UP/DOWN keys to navigate to the DATE screen. The
second line of the DATE screen displays the current date and is used by
the data logger for date stamping data records. The currently set date is
displayed on the second line of the display.
To change the currently set date:
1. Press ENTER to enter the date setup function. Note the
navigation arrows that appear on the left and right sides of
the display change from UP/DOWN to pointing
LEFT/RIGHT.
2. Use the UP/DOWN keys to alter the month. Then press
ENTER. The cursor will move over to the next editable field.
3. Use the UP/DOWN keys to alter the day. Then press
ENTER. The cursor will move over to the next editable field.
4. Use the UP/DOWN keys to alter the year. Then press
ENTER.
