5 Maintenance 5 Maintenance 5 Maintenance 5 Maintenance 5 Maintenance Model 3000P
5-8 Teledyne Analytical Instruments
X
X X
X
X
X
X
X
X X X
X X X
Figure 5-4: Rear-Panel Screws
To detach the rear panel, remove only the 14 screws marked with an X.
5.6 Cleaning
If instrument is unmounted at time of cleaning, disconnect the instru-
ment from the power source. Close and latch the front-panel access door.
Clean outside surfaces with a soft cloth dampened slightly with plain clean
water. Do not use any harsh solvents such as paint thinner or benzene.
For panel-mounted instruments, clean the front panel as prescribed in
the above paragraph. DO NOT wipe front panel while the instrument is
controlling your process.
