Percent Oxygen Analyzer Installation 3
3-1 Teledyne Analytical Instruments
Installation
Installation of the Model 3000PA Analyzer includes:
1. Unpacking
2. Mounting
3. Gas connections
4. Electrical connections
5. Installing the Micro-Fuel Cell
6. Testing the system.
3.1 Unpacking the Analyzer
The analyzer is shipped with all the materials you need to install and
prepare the system for operation. Carefully unpack the analyzer and inspect
it for damage. Immediately report any damage to the shipping agent.
3.2 Mounting the Analyzer
The Model 3000PA is for indoor use in a general purpose area. It is
NOT for use in hazardous environments of any type.
The standard model is designed for flush panel mounting. Figure 3-1 is
an illustration of the 3000PA standard front panel and mounting bezel. There
are four mounting holes—one in each corner of the rigid frame. The Draw-
ings section in the rear of this manual contains outline dimensions and
mounting hole spacing diagrams.
On special order, a 19" rack-mounting panel can be provided. For rack
mounting, one or two 3000 series analyzers are flush-panel mounted on the
rack panel. See Appendix for dimensions of the mounting panel.
