1-6
1 Introduction 1 Introduction 1 Introduction 1 Introduction 1 Introduction Model 3000PA
Teledyne Analytical Instruments
• Analog Outputs 0-1 V dc concentration output, plus
0-1 V dc range ID.
• Alarm Connections 2 concentration alarms and 1 system
alarm.
• Remote Valve Used in the 3000PA for controlling
external solenoid valves only.
• Remote Span/Zero Digital inputs allow external control
of analyzer calibration. (See Note,
below.)
• Calibration Contact To notify external equipment that
instrument is being calibrated and
readings are not monitoring sample.
• Range ID Contacts Four separate, dedicated, range relay
contacts. Low, Medium, High, Cal.
• Network For future expansion. Not
implemented at this printing.
Optional:
• Calibration Gas Ports Separate fittings for zero, span and
sample gas input, and internal valves
for automatically switching the gases.
• Current Signal Output Additional isolated 4-20 mA dc plus
4-20 mA dc range ID.
Note: If you require highly accurate Auto-Cal timing, use external
Auto-Cal control where possible. The internal clock in the
Model 3000PA is accurate to 2-3 %. Accordingly, internally
scheduled calibrations can vary 2-3 % per day.
