Teledyne 2240 - Portable Handheld Hydrogen Leak Detector, 3rd generation (revision 2/29/08) User Manual

Page 6

background image

Model

2240

Teledyne Analytical Instruments

vi

Table of Contents

List of Figures ............................................................................ viii

List of Tables ................................................................................ ix

Introduction ................................................................................... 1

1.1 Overview

1

1.2 Typical Applications

1

1.3 Features

2

1.4 Operator Interface

2

Startup and Operation .................................................................. 5

2.1 Unpacking the Instrument

5

2.2 Setup

6

2.3 Startup

6

2.4 Shutdown

7

2.5 Battery Level

7

2.6 Normal Operation

7

2.6.1 Hydrogen Concentration—LCD Display

8

2.6.2 Hydrogen Concentration—Probe Tip

8

2.7 Keypad

10

2.8 Controller LCD Error Status

10

2.9 Reset Operation

11

2.10 Zero Operation

11

2.11 Configuration Menu

11

2.12 Information Display

13

2.13 Reset Sensor

14

2.14 Zero Sensor

14

2.15 Field Calibrate

14

Field Verification and Calibration .............................................. 15
