Teledyne 2240 - Portable Handheld Hydrogen Leak Detector, 3rd generation (revision 2/29/08) User Manual
Page 22

Startup and Operation
Model 2240
Teledyne Analytical Instruments
12
following sections. The keypad is used to navigate the menu as shown in
Table 2-1.
Table 2-1: Navigation Button Functions
Key Navigation
Editing
Values
Query
Answer
ENTER Enter submenu
Select Value
Yes
▲
Previous Menu
Increase Value
No
▼
Next Menu
Decrease Value
No
►
Enter Submenu
Move Cursor Right
No
◄
Exit Submenu (Back) Move Cursor Left
No
◄ ►
Exit Configuration
Undo Changes
No
The functions accessible from the Configuration Menu are:
•
Information Display
•
Reset Sensor
•
Zero Sensor
•
Field Calibrate
•
Exit
These functions are described in the following sections. Figure 2-7
shows how to navigate through the Configuration Menu.
