Field Verify/Calibration

Model 2240

Teledyne Analytical Instruments

16

verification date. If Verify fails the field calibration values are erased,
restoring the last factory calibration.

To perform the verify test:

Table 3-1: Verify Calibration Procedure

Step

Display

User Response

1

Hydrogen <0.001% H2 Press ENTER.

2

Information Disp.

Press ▼

3

Reset Sensor

Press ▼

4

Zero Sensor

Press ▼

5

Field Calibrate
XX/XX/XX

Press ENTER or ►

6

Verify Sensor

Press ENTER

7

Verify Sensor
Are you sure?

Press ENTER to verify sensor, or any other key to
exit.

8

Verify Sensor in
Progress

Verify Test begins

9

Apply 0.000% H2
Are you sure?

With the Calibration Cup that accompanies the
instrument, apply hydrogen-free, ultra-zero air to the
Probe sensor. The Probe Tip LED will remain Green.
Press ENTER.

10

Apply 0.000% H2
In Progress

0% Verify Test starts

11

Apply 0.000% H2
Settle

Checking sensor temperature.

12

Apply 0.000% H2
Wait xxxx

Wait for sensor reading to stabilize, until xxxx = 0.

13

Apply 0.000% H2
Finding Average

Measuring sensor response to test gas.

14

Apply 0.100% H2
Are you sure?

With the Calibration Cup, apply 0.1% hydrogen
(balance air) to the Probe sensor. The Probe Tip
LED will change from Green to Red. One (or two)
yellow LEDs in the LED Bar Graph Array will turn on.
Press ENTER.

15

Apply 0.100% H2
In Progress

0.1% Verify Test starts
