Field Verify/Calibration

Model 2240

Teledyne Analytical Instruments

20

Step Display

User

response

15

Apply 0.100%H2
Are you sure?

With the Calibration Cup, apply 0.1% hydrogen
(balance air) to the Probe sensor. The Probe Tip
LED will change from Green to Red. One (or two)
yellow LEDs in the LED Bar Graph Array will turn
on. Press ENTER.

16

Apply 0.100%H2
In Progress

0.1% Calibration starts.

17

Apply 0.100%H2
Settle

Checking sensor temperature.

18

Apply 0.100%H2
Wait xxxx

Wait for sensor reading to stabilize until xxxx = 0.

19

Apply 0.100%H2
Finding Average

Measuring sensor response to test gas.

20

Apply 2.000%H2
Are you sure?

With the Calibration Cup, apply 2.0% hydrogen
(balance air) to the Probe sensor. The Probe Tip
LED will remain Red. Three yellow LEDs in the LED
Bar Graph Array will turn on. Press ENTER.

21

Apply 2.000%H2
In Progress

2.0% Calibration starts.

22

Apply 2.000%H2
Settle

Checking sensor temperature.

23

Apply 2.000%H2
Wait xxxx

Wait for sensor reading to stabilize until xxxx = 0.

24

Apply 2.000%H2
Finding Average

Measuring sensor response to test gas.

25

Calibrate Sensor
Done

Calibration is complete. Press ENTER.

26

Field Calibrate
XX/XX/XX

Press ▼

27

Exit

Press ▼

28

Information Disp

Press ▼

29

Reset Sensor

Carry out the Reset function to speed the recovery
from hydrogen. Press ENTER.
