Handheld Hydrogen Leak Detector Model 2240

Teledyne Analytical Instruments

Page 20 of 30

5.3

General Keypad Functions (Also See Section 11)

5.4

Information Display

The Information Display menu allows the user to view
useful information about the instrument including firmware
revisions, serial number, and calibration date. Enter it by
can be entered by pressing and holding the ENTER button.

5.5

Firmware Rev:

This displays the sensor pod and controller firmware. The
left most number preceded by an ‘S’ is the Probe firmware
revision. The right most number preceded by a ‘C’ is the
Controller firmware revision. For example: S1.23 C2.34
for Probe firmware version 1.23 and Controller firmware
version 2.34

5.6

Serial Number:

This displays the product serial number. For example:
50123

5.7

Calibration Date:

This displays the date of last factory calibration,
MM/DD/YY. For example: 5/8/06 for 8 May 2006.

5.8

Reset Sensor

The Reset Sensor menu is used to invoke the Reset
Operation as described in Section 4.6.

Key

Navigation

Editing Values

Query Answer

ENTER Enter

submenu

Select Value

Yes

▲ Previous

Menu

Increase Value

No

Next Menu

Decrease Value

No

► Enter

Submenu

Move Cursor Right

No

◄ Exit

Submenu
(Back)

Move Cursor Left

No

◄► Exit

Configuration

Undo Changes

No
