background image

Handheld Hydrogen Leak Detector Model 2240

Teledyne Analytical Instruments

Page 13 of 30

4. Operation

4.1

Startup

To power-up the Model 2240, press and hold the ON/OFF
button until the Controller LCD display indicates an
operational message.

Warning: Only power-up the instrument in a hydrogen-free
environment.

After power is on, the instrument takes about ten minutes
to warm-up. During this time the LCD displays a
countdown to completion and the Probe Tip LED is amber.
The following operations occur:

The Wide Range Sensor® reaches operating
temperature.

A system self-test is run.

Upon successful completion of the above tasks the
instrument zeroes itself and automatically switches to
normal operation. If an error is detected the instrument will
display an error code (see Section 10).

4.2

Shutdown

To power-down the Model 2240, press and hold the
ON/OFF button for approximately two seconds until the
Controller LCD display turns off.

4.3

Battery Level

After power-on the BATTERY LED indicates the current
battery level (times are approximate and may vary as the
battery ages
):

Color Meaning

Green

more than 60 minutes of operation
remaining

Amber

approximately 15 to 60 minutes of
operation remaining

Red

less than approximately 15 minutes of
operation remaining
