INSTALLATION
FTCS-IOM-2013-1114
SECTION 2
2-8
2” N.P.T. Gas
Connection
Manual Gas
Regulator
Manual Gas
Valve
Vent Valve
Gas Safety
Shutoff Valve
Manual Gas
Valve
HI/LOW
Gas Pressure Switch
Butterfly
Valve
Pilot Gas
Regulator
Pilot Gas
Valves
FIGURE 4 - TYPICAL GAS-FIRED MODULATED NFPA FUEL TRAIN
Gas Safety
Shutoff Valve
Main Gas
Regulator
Manual Gas
Valve
Pilot Gas
Regulator
Pilot Gas
Valve
Manual Gas
Valve
Butterfly
Valve
HI / LOW
Gas Pressure Switch
2” N.P.T. Gas
Connection
FIGURE 3 - TYPICAL GAS-FIRED MODULATED CSD-1 FUEL TRAIN
