27
4111-0014 — July 2013
PARTS
Power Pack Assembly
Item Quantity Part Number Description
1 2 2101-0017 HHCS-Grad 2-Zinc Plated, 3/8-16 UNC X 1
2 2 2101-0140 Lock Washer, 3/8
3 2 2401-0001 Grommet, 1-3/8 OD X 3/4 ID
4 1 2751-0016 J-Box Cover, 4 X 4
5 1 3051-0058 Capacitor-Motor Start, 66-77mf-330V
6 1 9301-0221 Fitting Connector 45 Deg, #4 ORB #4 JIC
7 1 9391-0040 Powerppac-PStop, 1PH-115V-1/4HP-1GPM
8 1 9391-0012 Powerppac Mounting Weldment
9 1 9391-0013 Cover-Pstop
10 REF 9904-0119 Hydraulic Hose ASM-1/4” 100R17 X 96, #4 JICF Swivel Both Ends
11 1 8581-0117 Valve, 4 Way
12 1 8581-0118 Delta Coil 115 volt (P Stop Only)
13 1 1751-0149 Decal “ No Step” (On Top of Cover)
* Hose Lengths Vary by Job
14 1 9395-0092 Powerpac (Includes Valve Body, Cover) complete
13 9
