PARTS
PowerStop M (Mechanical) Parts Breakdown
Item
Quantity
Part Number
Description
1
1
0191-0025
Bellows W/ 1 X 13=1/2 Velcro Strips
2
1
0941-0015
Spring, 1-7/8 DIA X 6.00
3
1
0615-0037
Stored Limit Switch with Bracket, NC
4
1
1751-0444
Decal-Systems, Inc./Powerstop, 3-3/4 X 14-1./2
5
1
1751-0010
Decal-Serial Number
6
1
1751-0135
Decal-Warning
7
2
2101-0009
HHCS-Grade 2-Zinc Plated, 5-16-18 UNC X 3/4
8
8
2101-0084
HHCS-Grade 5-Zinc Plated , 1/4-20 UNC X 3/4
9
1
2101-0085
Washer-Flat-Zinc Plated, 1-1/8 DIA
10
8
2101-0143
Nylon Lock Nut, 1/4-20 UNC
11
2
2101-0150
RHMS-Slotted, 10-24 UNC X 2-1/4
12
2
2101-0151
Nylon Lock Nut, #10-24 UNC
13
1
2101-0165
Shoulder Bolt,1/2 DIA X 5/8
14
8
2101-0189
E-Clip, 1/2
15
2
2101-0212
Flat Head Cap Screw, 1/2-13 UNC X 1
16
1
2103-0006
Anchor Kit Drive Way Mount
2103-0003
Anchor Kit Wall Mount
17
1
5455-0005
Level Weldment-Release
18
2
9202-0042
Pin-Pivot-Long, 1/2 DIA
19
2
9202-0043
Pin-Pivot-Short, 1/2 DIA
20
1
9411-0028
Shroud-Bellows Mounting-Pstop
21
2
9412-0161
Tube, 1-1/4 OD X 9-16 ID X 5/8
22
1
9412-0201
Bar-Bellows Mounting-Front
23
2
9412-0202
Bar-Bellows Mounting-Side
24
2
9412-0215
Bar-Bellows Mounting
25
1
9413-0049
Restraint Weldment-Pstop-Standard Profile-2 Stage
26
1
9413-0062
Scissor Lift Sub-Assembly-Pstop.
27
1
9413-0068
Spacer Assembly-Pstop Mechanical
28
1
9413-0070
Release Lever Assembly-Pstop Mechanical
29
1
9413-0087
Hook Stop-27”-Pstop
30
1
9414-0046
Final Base Weldment-27”-Pstop
*
1
9413-0098
Prox Over Travel (Not Shown)
