Page 25
23
4111-0014 — July 2013
PARTS
Item
Quantity
Part Number
Description
1
1
0191-0025
Bellows W/ 1 X 13=1/2 Velcro Strips
2
1
0524-0063
HYD Cylinder ASM, 1” Stroke
3
1
0524-0064
HYD Cylinder ASM, 5-3/4” Stroke
4
1
0615-0037
Stored Limit Switch with Bracket, NC
5
1
1751-0444
Decal-Systems, Inc./Powerstop, 3-3/4 X 14-1./2
6
1
1751-0010
Decal-Serial Number
7
2
2101-0009
HHCS-Grade 2-Zinc Plated, 5/16-18 UNC X 3/4
8
1
2101-0039
Nylon Lock Nut,5/16-18 UNC
9
8
2101-0084
HHCS-Grade 5-Zinc Plated, 1/4-20 UNC X 7/8
10
1
2101-0098
HHCS-Grade 5-Zinc Plated, 5/16-18 UNC X 1-3/4
11
8
2101-0143
Nylon Lock Nut, 1/4-20 UNC
12
2
2101-0150
RHMS-Slotted, 10-24 UNC X 2-1/4
13
2
2101-0151
Nylon Lock Nut, #10-24 UNC
14
1
2101-0163
Washer-Flat-Zinc Plated, 1/2 DIA X 5/8
15
1
2101-0165
Shoulder Bolt, 1/2 DIA X 5/8
16
1
2101-0187
HHCS-Grade 5, 5/16-18 UNC X 1
17
1
2101-0188
HHCS-Grade 5, 5/16-18 UNC X 1-1/4
18
8
2101-0189
E-Clip, 1/2”
19
2
2101-0202
RHMS-Phillips, 10-32 UNF X 1-3/4
20
2
2101-0212
Flat Head Cap Screw, 1/2-13 UNC X 1
21
1
2103-0006
Anchor Kit Drive Way Mount
2101-0003
Anchor Kit Wall Mount
22
2
9202-0042
Pin Pivot Long, 1/2 DIA
23
2
9202-0043
Pin Pivot Short, 1/2 DIA
24
1
9411-0024
Shroud-Cylinder, 1/16 X 2-1/16 X 4-1/2 X 6
25
1
9411-0028
Shroud-Bellows Mounting-Pstop
26
2
9412-0161
Tube, 1-1/4 OD X 9/16 ID X 5/8
27
1
9412-0201
Bar-Bellows Mounting-Front, Painted-1/8 X 1 X 7
28
2
9412-0202
Bar-Bellows Mounting-Side, Painted-1/8 X 1 X 23
29
1
9412-0215
Bar Bellows mounting, Painted-1/8 X 1 X 13
30
1
9413-0055
Restraint Weldment-Pstop-Low Profile
31
1
9413-0062
Scissor Lift Sub-Assembly-Pstop
32
2
9413-0069
Spacer Assembly-PStop-A
33
1
9413-0071
Release Lever Assembly
34
1
9413-0087
Hook Stop-27” Powerstop
35
1
9414-0046
Final Base Weldment-27”-Pstop
36
1
9904-0097
Hydraulic Hose ASM-1/4” 100R1 X 24”, #4 JICF Swivel Both Ends
37
1
9904-0119
Hydraulic Hose, 1/4” 100R1 X 96”, #4 JICF Swivel Both Ends
*
1
9413-0098
Prox Over Travel (Not Shown)
*
1
0522-0002
Spring, Helper, Rear Frame (Not Shown)
PowerStop A (Hydraulic) Parts Breakdown
