PASCO ME-6743 CART ADAPTER ACCESSORY User Manual
Cart adapter accessory, Instruction sheet for the pasco model me-6743
Instruction Sheet
for the PASCO
Model ME-6743
CART ADAPTER ACCESSORY
012-06877A
08/98
$1.00
© 1998 PASCO scientific
Introduction
The PASCO ME-6743 Cart Adapter Accessory is
used to attach the PASCO CI-6742 Motion Sensor II
to the PASCO Dynamics Carts and Motorized Carts.
Procedure
1. Attach the plate of the Cart Adapter Accessory
with the two thumbscrews (Figure 1).
2. Attach the Motion Sensor to the anchoring bolt,
turning the Motion Sensor until it is lightly
tightened onto the bolt.
3. Orient the Motion Sensor in the desired direction.
4. Turn the anchoring nut in a counter-clockwise
direction until the Motion Sensor is firmly locked
into place.
Figure 1
A Motion Sensor attached to a Dynamics Cart with the Cart
Adapter Accessory
thumbscrews
anchoring bolt
Cart Adapter
Accessory
anchoring nut
Motion Sensor II
Dynamics Cart
