M o d e l N o . O S - 8 4 5 8 S e t - u p
2
Warning label located on Product:
Set-up
1. Attach the laser to a Basic Optics bench by aligning the base
of the holder with the central channel of the bench and push-
ing down to snap it in place.
2. Squeeze the base of the holder and slide the laser along the
bench to the desired location.
3. Connect the AC adapter to a wall outlet and the power input
jack.
4. Slide the power switch on the back of the laser to turn the
beam on or off.
5. Turn the vertical and horizontal adjustment screws to aim the
beam.
Notes
• These lasers are designed for use in room temperature envi-
ronments (10° C to 35° C).
• For optical power stability, allow the laser to warm up for 5
to 10 minutes.
• These lasers are designed for use in student labs and class-
room demonstrations.
• To maximize laser life, turn off the laser when it is unat-
tended or not in use.
Specifications
Technical Support
For assistance with any PASCO product, contact PASCO at:
Limited Warranty
For a description of the product warranty, see the PASCO catalog.
__________________________________________________________
➧
NOTE: NO service or maintenance is allowed, on this product, by
the customer. Return unit to the factory for service or repair.
Unit is NOT to be opened or modified by the Customer.
__________________________________________________________
Copyright
The PASCO scientific 012-09867A Basic Optics Diode Laser Instruction
Sheet is copyrighted with all rights reserved. Permission is granted to
non-profit educational institutions for reproduction of any part of this man-
ual, providing the reproductions are used only in their laboratories and
classrooms, and are not sold for profit. Reproduction under any other cir-
cumstances, without the written consent of PASCO scientific, is prohibited.
Trademarks
PASCO and PASCO scientific are trademarks or registered trademarks of
Complies with FDA
performance standards for
laser products except for
deviations pursuant to Laser
Notice No. 50, dated June 24, 2007
LASER LIGHT
DO NOT STARE
INTO BEAM
CLASS 2 LASER PRODUCT
650nm, <1mW CW (Red)
CLASSIFIED 60825-1 2007
Classification Class II Laser
Wavelength 532 nm (green)
650 nm (red)
Maximum Output <1 mW
Divergence <2 mrd
Beam Diameter at aparture 3 mm
Address: PASCO scientific
10101 Foothills Blvd.
Roseville, CA 95747-7100
Phone: 916-786-3800 (worldwide)
800-772-8700 (U.S.)
Fax: (916) 786-7565
Web: www.pasco.com
Email: [email protected]
