PASCO OS-8516A Ray Optics Kit - Manual (Page 2)

®
M o d e l N o . O S - 8 5 1 6 A S p e c i f i c a t i o n s
2
Specifications Technical Support
For assistance with any PASCO product, contact PASCO at:
Limited Warranty
For a description of the product warranty, see the PASCO catalog.
Copyright
The PASCO scientific 012-05627G
Ray Optics Kit Instruction Sheet is
copyrighted with all rights reserved. Permission is granted to non-profit
educational institutions for reproduction of any part of this manual, provid-
ing the reproductions are used only in their laboratories and classrooms,
and are not sold for profit. Reproduction under any other circumstances,
without the written consent of PASCO scientific, is prohibited.
Trademarks
PASCO and PASCO scientific are trademarks or registered trademarks of
PASCO scientific, in the United States and/or in other countries. All other
brands, products, or service names are or may be trademarks or service
marks of, and are used to identify, products or services of, their respective
owners. For more information visit www.pasco.com/legal.
Mirror
Sides Convex, Concave, and Plane
Radius of curvature 12.5 cm
Width of each side 6 cm
Height 1.5 cm
Convex and Concave Lenses
Shape Convex-convex and
concave-concave
Radius of curvature 12.7 cm
Width 5.7 cm
Height 3.8 cm
Material Acrylic
Index of refraction 1.49
Acrylic Rhombus
Angles of corners 90°, 90°, 45°, 135°
Width of sides 3.2 cm, 3.2 cm, 6.4 cm, 4.5 cm
Height 2.5 cm
Index of refraction 1.49
Hollow Lens
Radii of curvature 5 cm and 3 cm
Width 5.1 cm
Total thickness 3.3 cm
Height 2.7 cm
Address: PASCO scientific
10101 Foothills Blvd.
Roseville, CA 95747-7100
Phone: 916-786-3800 (worldwide)
800-772-8700 (U.S.)
Fax: (916) 786-7565
Web: www.pasco.com
Email: [email protected]
