012-06859B Pressure Sensor - Absolute (0 to 700 kPa)
5
Limited Warranty
PASCO scientific warrants the product to be free
from defects in materials and workmanship for a
period of one year from the date of shipment to the
customer. PASCO will repair or replace, at its
option, any part of the product which is deemed to
be defective in material or workmanship. The
warranty does not cover damage to the product
caused by abuse or improper use. Determination of
whether a product failure is the result of a
manufacturing defect or improper use by the
customer shall be made solely by PASCO
scientific. Responsibility for the return of
equipment for warranty repair belongs to the
customer. Equipment must be properly packed to
prevent damage and shipped postage or freight
prepaid. (Damage caused by improper packing of
the equipment for return shipment will not be
covered by the warranty.) Shipping costs for
returning the equipment after repair will be paid by
PASCO scientific.
Address: PASCO scientific
10101 Foothills Blvd.
Roseville, CA 95747-7100
Phone: (916) 786-3800
FAX: (916) 786-8905
email: [email protected]
web: www.pasco.com
Note: This instruction sheet was written assuming
that the user has a basic familiarity with
Science Workshop and has access to the User’s
Guide for Science Workshop. Users can gain
basic skills by working through the tutorial within
Science Workshop. Another useful resource is the
Quick Reference Card for Science Workshop.
DIN Connector Specifications
1: analog output (+), -10 to +10 V
2: analog output (-), signal ground
3: (no connection)
4: + 5 V DC power
5: power ground
6: +12 VDC power
7: -12 VDC power
8: (no connection)
00 kPa MAX
DRY
AIR
ONL
Y
PR ESSURE PORT MA
TING
CONNECT
OR:
PASCO P
ART NO. 640-021
1
4
3
5
2
6 7
8
