31 57-600 Eclipse ® Guided Wave Radar Transmitter
2.6.5.4 Measurement Type: Interface and Volume
Display Action Comment
24
BlockDis
xx.x lu
Enter distance below
reference point where level is
not sensed Allows user to ignore level measurements near the top of the
probe
25
SZ Fault
(select)
Select lop current behavior
when level is sensed in safety
zone Safety Zone is a user-defined area just below the Blocking
Distance. Enable Fault if necessary to ensure safe, reliable high-
level readings in critical applications. Choices are None, 3.6 mA,
22 mA, Latch 3.6 or Latch 22. If Latch 3.6 or Latch 22 is
selected, the loop current will remain in alarm until it is manually
cleared with the SZ Alarm Reset below (#27)
26
SZ Height
xx.x lu
Enter distance below
BlockDis where SZ Fault will
be asserted Enter a distance value that develops a safety zone just below the
Blocking Distance. Here the unit will report a Safety Zone Fault
(#25) if the level rises into this area.
27 SZ Alarm Reset
Press Enter to clear a
latched Safety Zone alarm Clear a latched Safety Zone alarm
28
Threshld
(select)
Select from CFD, Fixed For interface, refers to threshold for upper level pulse. (Set to
Fixed for most common applications.)
29
IfcThrsh
(select)
Select from CFD, Fixed Interface mode only. Threshold for interface level pulse. (Set to
CFD for most common applications.)
30
Poll Adr
xx
Enter HART polling address
number (0-63) Select a HART poll address (0–63). Enter 0 for a single
transmitter installation. Poll address does not affect loop current.
31 Loop Mode
Enable/Disable Determines whether the loop is fixed at 4.0 mA or controlled by
the PV.
32
Trim Lvl
xx.x lu
Enter value to adjust Level
reading -10.0 inches <= Lvl Trim <= +10.0 inches
(Requires superuser password)
33
Trim 4
xxxx
Fine tune the 4 mA point Adjust setting to output exactly 4.0 mA on current meter
34
Trim 20
xxxx
Fine tune the 20 mA point Adjust setting to output exactly 20.0 mA on current meter
35
Loop Tst
xx.x mA
Enter a mA Output value Set mA output to any given value to perform loop test
36
LvlTicks
Xxxxx
Diagnostic Display Time of flight from fiducial to interface signal
37
IfcTicks
Xxxxx
Diagnostic Display Interface mode only
Time of flight through upper liquid
38 Medium
Diagnostic Display Interface mode only
Displayed messages are: Unknown, Oil Only, Thin Oil, Thick Oil
39
New Pass
Xxx
Enter new password (0-255) Displays encrypted value of present password
40
Language
(select)
Select from English, Spanish,
French, German Language choice for LCD display. (no HART counterpart)
41
Mdl705HT
Ver3.0a0
Transmitter display Product identification. Firmware version
42
DispFact
(select) Select Yes to display factory
parameter menus Allows for viewing the factory parameters
43
History
(current status)
Press Enter to view history
of recent exceptions Diagnostic Display
44
HF cable
(select)
Superuser Parameter Select from 3-foot or 12-foot remote
45 Run Time
