115 v, 230 v – Nova-Tech Digi-Sense Termperature Controller RS (Standard Models) User Manual
Page 10

7
3. Plug the unit in to a correctly rated AC outlet and turn on the power using
the ON/OFF switch on the back panel. Refer to Figure 5.
115 V
Heater/Cooler
Output Fuse
Heater Cord
Cable Connection
ON/OFF
Switch
Mini-ANSI Thermocouple
Jack (500 ohm Max
Load Resistance)
Heater Cord
Cable Connection
Heater/Cooler
Output Fuse
ON/OFF
Switch
Instrument
Fuse
Instrument
Fuse
Mini-ANSI Thermocouple
Jack (500 ohm Max
Load Resistance)
4. Connect one of the eight types of thermocouples to the unit.
5. Connect the heater or cooler (maximum of 10 A) to the unit.
230 V
FIGURE 5. BACK PANEL VIEWS (115 V AND 230 V)
Power Line
Cord Connection
