Device Dimensions
568B Pin out Termination
WWW.NITEK.NET
OPTIONAL
Power Input, Class 2
48 to 56VDC, 800mA
Power
Link Status
Network
Port
See Installation Manual
for Hookup Instructions
Made in USA
Link To
Receiver
PoE OUT
10/100
NITEK
ET1551U
Transmitter
Top
Bottom
Right
Left
3.9”
1.1”
1.1”
4.6”
1.6”
1.6”
IEC/UL 60950-1
