Nitek TS560x4 - Manual

Note: This installation should be made by a
qualified service person and conform with local
codes.
System Specifications
TR560x4 includes the following: TS560x4 System includes the following:
(1) TR560x4 Receiver Card (1) TR560x4 Receiver Card
(4) VB37F Transmitters
Model TR560x4
Modular Active Video Receiver Card
Installation and
Operation Manual
Rev 030111
NITEK
®
Europe Office:
De Schans 19-21 2a, 8231 KA Lelystad
The Netherlands
Tel: +31(0)320-2300005
Fax: +31(0)320-282186
E-mail: [email protected]
WWW.NITEK.NL USA Office:
5410 Newport Drive, Rolling Meadows, IL 60008
Phone: (800) 528-4343
Fax: (847) 259-1300
E-mail: [email protected]
WWW.NITEK.NET
685600103
Reduce risk of fire or electrical shock. Do not
expose this product to rain or moisture.
!
Installation
1) Check the twisted pair for continuity. Do this by shorting the pair of wires at one end and using an ohm
meter to check the resistance at the other end. The chart below will give you the length of your wires for a
measured resistance. Use a multimeter to make sure there is no voltage on the line.
For distances greater than 3,000 feet, there are several other systems available. Contact your local
Distributor or Nitek Technical Department for assistance.
The TR560x4 receiver can be used with any standard twisted pair video camera or Balun type transceiver device.
Steps 2 and 3 refer to the Nitek VB37 Balun.
Wire
Gage
300
(90)
500
(150)
1000
(300)
1500
(450)
2000
(600)
2500
(750)
3000
(900)
22 10 6 32 48 64 80 96
24 15 25 51 76 102 127
153
26 25 41 82 123 164 205 246
Distance in Feet (Meters)
Model TS560x4
Modular Active Video Receiver Card
w/Transmitters
Introduction
Twisted Sender has been designed by Nitek to transmit video signals over a point to point pair of wires. The wire
should be free of voltage or other outside signals. Twisted Sender can turn your in-house phone lines, leased
telephone lines or cable runs into pathways for video signals. Twisted Sender is ideal for shopping malls, parking
garages, remote gates, large factories, airports or any number of places where you need to connect video
equipment.
Receiver Unit Transmitter Unit
Size 1 card slot Size 1.3”H x 2.0”W x .95”D
Power Requirements Power supplied by Card Cage Power Requirements None
Input (4) Low voltage current loop Input-Video 1 vpp composite video
from transmitter unit Monochrome or Color
Output-Video (1) 1.0 vpp composite video
Monochrome or Color
