Dixon Valve 50 TON RAM SEC05 External Swaged Cam And Groove User Manual
Page 12
50 Ton Ram Instruction Manual
Cam & Groove Holedall Couplings
customer service
800
•
355
•
1991
10
Section 5
Dixon Valve and Coupling Company recommends that all
hose assemblies be tested as recommended by the Rubber Manufacturers Association.
Pushers and Spacer Rings For Cam & Groove
Note: Spacer Rings are to be used with Type 'C' Couplings ONLY.
DO NOT use Spacer Rings with Type 'E' Couplings, or bodily injury may result.
* Future designs may not require Spacer Rings.
Contact the Factory for more information
Size
Description
Part Number
100PUSHCG4E
100PUSHCG4C
300CGSPACE
1"
1½"
2"
3"
4"
Type 'E' Pusher
Type 'C' Pusher
Spacer Ring *
RE100PUSH
100PUSHCGRC
100CGSPACE
Type 'E' Pusher
Type 'C' Pusher
Spacer Ring *
100PUSHCG15E
100PUSHCG15 (
2 pieces
)
150CGSPACE
Type 'E' Pusher
Type 'C' Pusher
Spacer Ring *
Type 'E' Pusher
Type 'C' Pusher
Spacer Ring *
Type 'E' Pusher
Type 'C' Pusher
Spacer Ring *
100PUSHCG2
100PUSHCG2
200CGSPACE
100PUSHCG3
100PUSHCG2
300CGSPACE
