HB Coupling Expander Instructions
EFFECTIVE JANUARY 2009
HB Manual Coupling Expanding Machine
Coupling Types: 520-H, 570-H and 580-H
Coupling Sizes: 5/8" to 2"
HB expander includes the following replaceable parts
Tooling Needed for HB Expander
Punch, reducer and close nipple for each size.
2" requires punch and standard coupling ONLY.
For 1-3/8" fittings, reducers and nipples use 1½".
H-820 5/8" punch
H-607 3/4" punch
H-601 1" punch
H-608 1¼" punch
H-602 1-3/8" punch
H-603 1½" punch
H-604 2" punch
HB-106 2" x 3/4" standard reducer (BR2075)
HB-105 2" x 1" standard reducer (BR2010)
HB-104 2" x 1¼" standard reducer (BR2012)
HB-103 2" x 1½" standard reducer (BR2015)
HB-102 2" standard coupling (RHC200)
HB-110 3/4" x 1-3/8" close nipple (CN075)
HB-109 1" x 1½" close nipple (CN100)
HB-108 1¼" x 1-5/8" close nipple (CN125)
HB-107 1½" x 2-3/4" close nipple (CN150)
25000HTL01
25000HTL02
25000HTL03
25000HTL04
25000HTL05
25000HTL06
25000HTL07
2500HBTL01
2500HBTL02
2500HBTL03
2500HBTL04
2500HBTL05
2500HBTL06
2500HBTL07
2500HBTL08
2500HBTL09
Part Number Description
HB-201 body
HB-202 drive screw nut
HB-204 thrust connector
HB-203 thrust connector pin (2 required)
HB-207 drive screw with key
HB-208 handle (2 required)
HB-209 lock screw
HB-101 thrust bearing
H-213 punch retaining nut
H-212 key
2500HB0001
2500HB0002
2500HB0003
2500HB0004
2500HB0005
2500HB0006
2500HB0007
2500HB0008
25000HSP11
25000HSP15
Part Number Description
HB Coupling Expanding Machine 2500HB0000
Part Number Description
