8. At the start of the cut line, lower the blade back into

the cut and make a second, deeper pass across the
entire cutting line.

9. Continue the step-cut process to reach the

maximum depth. DO NOT cut any deeper than
required.

Making a Cut Using the Blade Depth Stop

1. Align the blade and cutting guide(s) with the cut line.
2. If the saw is equipped with a clutch (optional), turn

on the Blade Clutch switch with the engine at idle to
start the blade rotation.

3. Turn on the water and adjust the water flow.
4. Lower the blade to just above the cutting surface

and set the cutting depth indicator at zero.

5. Turn on the Auto Water switch if desired for

automatic water on/off when cutting.

6. Slowly lower the blade into the surface to the

desired cut depth. Note: Initial cut should be less
than 2 inches.

7. Push

the

Blade Depth Stop button to the “Set Blade

Depth” position. The Blade Depth Set light will turn
on, which means the cutting depth is set.

8. Raise the blade out of the cut and reposition the saw

at the start of the cut. DO NOT move backwards with
the blade in a previous cut.

9. Push

the

Blade Depth Stop button to the “Override

Blade Depth” position and hold it down for
approximately three seconds, noting when the Blade
Depth Set light goes out. Set the cutting depth at a
different depth measurement following guidelines in
steps 6 & 7.

10. Continue the step-cut process using the depth stop

to reach the maximum depth. DO NOT cut any
deeper than required.

Continuing a Partial-Cut

1. Maneuver the saw to the desired location.
2. Align the blade with the previous cut and slowly

lower the blade back into the concrete. Use extreme
caution to make sure the blade is perfectly aligned
within the cut. DO NOT continue cutting until the
blade is aligned within the cut!

3. Continue the step-cut process (using the blade

depth stop if preferred) to reach the maximum depth.
DO NOT cut any deeper than required.

Finishing a Cut

1. Place the speed control lever at Stop.
2. Raise the blade from the cut (provide proper ground

clearance).

3. If the saw is equipped with a clutch (optional), turn

off the Blade Clutch switch with engine at idle to stop
the blade rotation.

4. Turn off the Auto Water switch and water supply.
