ITEM PART NO. QTY. DESCRIPTION
1 2503183 1 Vernier Throttle Cable
2 6045115 1 Throttle Bracket
3 2900329 1 Cap Screw, Hex Hd., M8-1.25 x 20mm
4 2901021 1 Cap Screw, Hex Hd., M10-1.25 x 20mm
5 2900763 1 Lock Washer, M8 Split
6 2900321 1 Lock Washer, M10 Split
7 2901135 1 1/4" 'X' Washer
8 2501603 1 Set Collar, 3/8" with Set Screw
9 2503945 2 Cable Anchor
10 2900016 6 Flat Washer, #10 USS
11 2900301 2 Lock Nut, M5-0.8 Nylon Insert
12 2503918 1 Wire Stop Pivot Pin
13 2900034 1 Cotter Pin, 3/32" x 3/4"
14 2900114 1 Machine Screw, Rd. Hd., #8-32 x 3/8"
11
7
4
6
3 5 2
14
12
13
1
9
10
8
Throttle Cable Assembly #6045044
43
