Diamond Products CC4144D (3 Speed) User Manual
Page 31

Assembly Notes:
Apply 2401311 thread sealant to all male pipe threads and screw threads on 2800169 magnetic sensor
1.
Screw sensor into port until tip touches OD of tach gear, back sensor out 1/2 turn and lock in place w/ jam nut
2.
Apply 2401315 Loctite #242 to all set screw threads & 2401316 Loctite #262 to all cap screw threads
3.
Lubricate all O-Rings, seal lips and shaft journals with 2502046 grease
4.
Seal all gasket surfaces with 2503802 Permatex Ultra Black
5.
ITEM
PART NO.
QTY.
DESCRIPTION
1
6018058
1
Right Side Transmission Cover
2
2900982
2
Dowel Pin, 1/4" Dia. x 1"
3
2900176
6
Cap Screw, Soc. Hd., 5/16-18 x 1-1/4"
4
2900142
6
Set Screw, Soc. Hd., 5/16-18 x 3/8"
5
6018301
1
RH Bladeshaft Housing
6
2506433
1
O-Ring, AS568A-154 Viton
7
2900103
2
Cap Screw, Soc. Hd., 5/16-18 x 1"
8
2900191
4
Cap Screw, Soc. Hd., 5/16-18 x 2-1/2"
9
3200153
1
Pipe Plug, 3/8" NPT
10
2900805
1
Sealing Washer, 5/8"
11
2800169
1
Magnetic Sensor w/Jam Nut
12
2502199
1
Retaining Ring, 85mm Internal
13
2503944
1
Oil Seal, 45 x 85 x 10mm
14
6018049
1
Seal Retainer
15
2900978
4
Cap Screw, Flat Hd., #10-24 x 1/2"
16
2500939
1
O-Ring, AS568A - 010
17
2900061
1
Grease Fitting, 1/4-28 x 90 Degree
18
2500751
1
Seal, 1-3/4" V-Ring
19
6018028
1
V-Ring Cover
20
6018064
1
Shift Bracket
21
2903244
1
Dowel Pin, 1/4" Dia. x 1/2"
22
6018065
1
Shifter Housing
23
2506441
1
Oil Seal, 1/2 x 1.00 x 1/4"
24
2401311
AR
Loctitie #567 Thread Sealant
25
2401315
AR
Loctite #242 Blue
26
2401316
AR
Loctite #262 Red
27
2502046
AR
Grease, Fuchs Synthetic
28
2503802
AR
Permatex Ultra Black
Right Hand Side Cover, 3- Speed Transmission, #6018402
