Assembly Notes:
Apply 2401315 Loctite #242 to all set screw threads & 2401316 Loctite #262 to all cap screw threads
1.
Lubricate all O-Rings, seal lips and shaft journals with 2502046 grease
2.
Seal all gasket surfaces with 2503802 Permatex Ultra Black
3.
ITEM
PART NO.
QTY.
DESCRIPTION
1
6018057
1
Left Side Transmission Cover
2
2503965
1
Wave Washer, 80mm OD
3
2503966
1
Wave Washer, 62mm OD
4
2900982
2
Dowel Pin, 1/4" Dia. x 1"
5
2900176
6
Cap Screw, Soc. Hd., 5/16-18 x 1-1/4"
6
2506443
1
Oil Seal, 40 x 60 x 10mm
7
2900142
4
Set Screw, Soc. Hd., 5/16-18 x 3/8"
8
2506433
1
O-Ring, AS568A-154 Viton
9
6018302
1
LH Bladeshaft Housing
10
2900103
2
Cap Screw, Soc. Hd., 5/16-18 x 1"
11
2900191
4
Cap Screw, Soc. Hd., 5/16-18 x 2-1/2"
12
2503826
1
85mm Wave Washer
13
2502199
1
Retaining Ring, 85mm Internal
14
2503944
1
Oil Seal, 45 x 85 x 10mm
15
6018049
1
Seal Retainer
16
2500751
1
Seal, 1-3/4" V-Ring
17
6018028
1
V-Ring Cover
18
2500939
1
O-Ring, AS568A - 010
19
2900061
1
Grease Fitting, 1/4-28 x 90 Degree
20
2900978
4
Cap Screw, Flat Hd., #10-24 x 1/2"
21
2401315
AR
Loctite #242 Blue
22
2401316
AR
Loctite #262 Red
23
2502046
AR
Grease, Fuchs Sythentic
24
2503802
AR
Permatex, Ultra Black
Left Hand Side Cover, 3-Speed Transmission, #6018403
