Diamond Products CC4144D (3 Speed) - Manual (Page 27)

ITEM PART NO. QTY. DESCRIPTION
1 6045360 1 Belt Tension Bracket Box
2 2900014 8 Flat Washer, 3/8" SAE
3 2900006 4 Lock Washer, 3/8" Split
4 2900005 4 Cap Screw, Hex Hd., 3/8-16 x 1"
5 6045362 1 Turnbuckle, 1/2" Eyes
5.1 6045374 1 Rod End, Right Hand, 1/2"-13 x 3-1/2"
5.2 2901013 1 Coupling Nut, 1/2-13 x 4 LH/RH
5.3 2900129 1 Jam Nut, 1/2-13
5.4 6045366 1 Rod End: Left Hand 1/2"-13 x 3-1/2"
6 2900139 2 Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
7 2900058 4 Flat Washer, 1/2" SAE
8 2900026 2 Lock Nut, 1/2-13 Nylon
9 6045361 1 Belt Tension Bracket, Engine
10 2900321 4 Lock Washer, M10 Split
11 2900870 4 Cap Screw, Hex Hd., M10-1.25 x 30mm
Turnbuckle Tensioning Assembly #6045446
5.3
9
6
7
2
10
11
6
7
1
4
3
2
5.4
7
8
8
7
5.1
5.2
27
