Blade Speed Conversion Charts (CC3725E / CC3730E)
WARNING:
Blade Size
Max. Depth
of Cut
No Load RPM Sheave Size No Load RPM Sheave Size
14" 3,050 3.12" 1,800 5.3" 4-1/2"
20" 2,350 3.65" 1,800 4.75" 7-1/2"
26" 1,800 4.12" 1,800 4.12" 10-1/2"
30" 1,550 4.75" 1,800 4.12" 11-3/4"
36" 1,375 4.75" 1,800 3.65" 14-3/4"
WARNING:
14" 20" 26" 30" 36"
6010950 6010952 6010954 6010956 6010958
6011093
(5.3")
6011094
(4.75")
6012024
(4.12")
6012024
(4.12")
6012056
(3.65")
6012005
(3.12")
6011009
(3.65")
6011010
(4.12")
6012052
(4.75")
6012052
(4.75")
6010036
(4.5")
6010036
(4.5")
6010036
(4.5")
6010038
(6")
6010038
(6")
6010037
(4.5")
6010037
(4.5")
6010037
(4.5")
6010039
(6")
6010039
(6")
Bottom Set Bottom Set Bottom Set Top Set Top Set
When changing blade size, use chart shown below for selecting items that must be changed.
Outer Flange
(Flange Size)
Skid Plate
Mounting Holes
Do not exceed blade speed (RPM) shown for each blade size.
Excessive blade speed could result in blade breakage and serious personal injury!
Blade Shaft Motor
Motor Sheave, 1-7/8" Bore
(Sheave Size)
Blade Shaft Sheave, 1-3/4" Bore
(Sheave Size)
Inner Flanges (2)
(Flange Size)
Models CC3725E / CC3730E
Blade Guard Assembly
