Controls Legend
1 Hour Meter 10 Speed Control Lever
2 Amp Meter 11 Lower Pushbutton
3 Battery Charge Meter 12 Raise Pushbutton
4 Motor Start Button 13 Transmission Engagement Lever *
5 Motor Stop Button 14 Transmission Engagement Lever **
6 Depth Stop Knob 15 Water Pump Switch (Optional)
7 Cutting Depth Indicator 16 Spotlight Switch (Optional)
8 Water Valve 17 Lowering Speed Metering Valve (Optional)
9 Handle Lock Knobs * For Eaton Transmission Only
** For Sundstrand Transmission Only
