25hp Motor Mount Assembly #6012144
ITEM PART NO. QTY. DESCRIPTION
1 2600133 1 Motor, 25hp Leeson
2 6010011 1 Engine Base Weldment
3 6012018 2 Motor Spacer
4 2900058 4 Flat Washer, 1/2" SAE
5 2900084 4 Lock Washer, 1/2" Split
6 2900139 4 Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
7 2900002 7 Flat Washer, 5/8" SAE
8 2900113 4 Lock Washer, 5/8" Split
9 2900512 4 Cap Screw, Hex Hd., 5/8-11 x 1-1/4"
10 2900104 2 Tap Bolt, Hex Hd., 5/8-11 x 6"
11 2900112 2 Hex Nut, 5/8-11
12 2900446 2 Swivel Pad Nut, 5/8-11
13 6010012 1 Frame Lift
14 6010013 1 Frame Lift Brace
15 2900721 3 Flat Washer, 5/8" USS Hardened
16 2900135 4 Lock Nut, 5/8-11 Nylon
17 2900147 2 Cap Screw, Hex Hd., 5/8-11 x 1-3/4"
18 2900136 1 Cap Screw, Hex Hd., 5/8-11 x 2"
19 2900286 1 Cap Screw, Button Hd., 5/8-11 x 2"
20 2900013 1 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
21 2900005 1 Cap Screw, Hex Hd., 3/8-16 x 1"
22 2900018 2 Lock Nut, 3/8-16 Nylon
23 2600347 1 Motor, 25hp Leeson (575 Volt)
