Starter Box Unit #2800215
ITEM PART NO. QTY. DESCRIPTION
1 2800240 1 Enclosure
2 2800249 1 Subpanel
3 6011329 1 Stop Button Assembly
2800599 1 Stop Button Body & Cap
2800200 1 Contact Block (N.C.)
1800922 1 Stop Label
4 6011097 1 Start Button Assembly
2701390 1 Start Button Body
2701392 1 Contact Block (N.O.)
2800317 1 Green Button Cap
2800222 1 Clear Protective Boot
1800923 1 Start Label
5 2800224 1 Battery Charge Ammeter
6 2800245 1 Reset Button
7 2707338 1 Disconnect Handle
8 2800552 1 Connector, 1/2" Cord
9 2800312 2 Connector, 1" Sealtite Elbow
10 2701274 1 Rectifier Bridge
11 2800299 2 Fuse Holder, 30A-600V Dual
12 2800400 1 Auxiliary Contact (N.O.)
13 2800401 1 Motor Contactor, Siemens
14 2800402 1 Coil, 24V-AC
15 2800403 1 Overload Relay, 25-100A
16 2800248 1 Current Transformer
17 2707339 1 Disconnect Block
18 2707337 1 Disconnect Shaft
19 2800315 1 Grounding Lug
20 2701299 1 Transformer, 500VA
21 2701295 1 Power Relay, 12V-DC
22 2701066 1 Fuse, ATQR 10A
23 2701307 1 Fuse, ATMR 25A
24 2701273 2 Fuse, ATQR 4A
