Diamond Products CC3700E User Manual
Page 43
40hp Motor Mount Assembly #6012146
ITEM
PART NO.
QTY.
DESCRIPTION
1
2600185
1
Motor, 40hp Lincoln
2
6010011
1
Engine Base Weldment
3
6012034
2
Motor Spacer
4
6012035
2
Motor Connect Spacer
5
2900002
13
Flat Washer, 5/8" SAE
6
2900113
5
Lock Washer, 5/8" Split
7
2900135
9
Lock Nut, 5/8-11 Nylon
8
2900512
1
Cap Screw, Hex Hd., 5/8-11 x 1-1/4"
9
2900527
4
Cap Screw, Hex Hd., 5/8-11 x 2-1/2"
10
2900195
1
Cap Screw, Hex Hd., 5/8-11 x 3"
11
2900137
4
Cap Screw, Hex Hd., 5/8-11 x 3-1/4"
12
2900385
2
Set Screw, Sq. Hd., 5/8-11 x 8"
13
2900112
2
Hex Nut, 5/8-11
14
2900446
2
Swivel Pad Nut, 5/8-11
15
6010012
1
Frame Lift
16
6010013
1
Frame Lift Brace
17
2900721
3
Flat Washer, 5/8" USS Hardened
18
2900147
2
Cap Screw, Hex Hd., 5/8-11 x 1-3/4"
19
2900136
1
Cap Screw, Hex Hd., 5/8-11 x 2"
20
2900286
1
Cap Screw, Button Hd., 5/8-11 x 2"
21
2900013
1
Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
22
2900005
1
Cap Screw, Hex Hd., 3/8-16 x 1"
23
2900018
2
Lock Nut, 3/8-16 Nylon
24
2500676
1
Motor Cord Adapter Plate
25
2900201
4
Rivet, 3/16" Dia.
26
2600250
1
Motor, 40hp Lincoln (575 Volt)
