Diamond Products CC3700E User Manual
Page 41
30hp Motor Mount Assembly #6012145
ITEM
PART NO.
QTY.
DESCRIPTION
1
2600182
1
Motor, 30hp Lincoln
2
6010011
1
Engine Base Weldment
3
6012034
2
Motor Spacer
4
6012035
2
Motor Connect Spacer
5
2900058
4
Flat Washer, 1/2" SAE
6
2900084
4
Lock Washer, 1/2" Split
7
2900025
4
Cap Screw, Hex Hd., 1/2-13 x 1-1/4"
8
2900002
8
Flat Washer, 5/8" SAE
9
2900113
5
Lock Washer, 5/8" Split
10
2900135
6
Lock Nut, 5/8-11 Nylon
11
2900512
1
Cap Screw, Hex Hd., 5/8-11 x 1-1/4"
12
2900527
4
Cap Screw, Hex Hd., 5/8-11 x 2-1/2"
13
2900558
2
Cap Screw, Soc. Hd., 5/8-11 x 2-3/4"
14
2900385
2
Set Screw, Sq. Hd., 5/8-11 x 8"
15
2900112
2
Hex Nut, 5/8-11
16
2900446
2
Swivel Pad Nut, 5/8-11
17
6010012
1
Frame Lift
18
6010013
1
Frame Lift Brace
19
2900721
3
Flat Washer, 5/8" USS Hardened
20
2900147
2
Cap Screw, Hex Hd., 5/8-11 x 1-3/4"
21
2900136
1
Cap Screw, Hex Hd., 5/8-11 x 2"
22
2900286
1
Cap Screw, Button Hd., 5/8-11 x 2"
23
2900013
1
Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
24
2900005
1
Cap Screw, Hex Hd., 3/8-16 x 1"
25
2900018
2
Lock Nut, 3/8-16 Nylon
26
2500676
1
Motor Cord Adapter Plate
27
2900201
4
Rivet, 3/16" Dia.
28
2600238
1
Motor, 30hp Lincoln (575 Volt)
41
