Diamond Products CC3700E User Manual
Page 77
DC Power Travel Option 230/460V
#6011620
ITEM
PART NO.
QTY.
DESCRIPTION
1
6011590
1
Starter Box Assembly 230/460V for DC Travel Option
2
2802011
1
Circuit Breaker, 80 Amp
3
4646015
2
Battery Cable Assy., Red
4
4646016
1
Battery Cable Assy., Black
5
2600882
1
3/4HP Leeson Motor. 12VDC 1750 RPM
6
6012205
1
Motor Platform
7
2900138
8
Cap Screw, Hex Hd., 5/16-18 x 1"
8
2900567
16
Flat Washer, 5/16" USS
9
2505382
1
Pulley, 4" Single Groove
10
6048218
1
Idler Arm
11
2500508
1
Idler Pulley 3"
12
2900033
1
Hex Nut, 3/8-16
13
2900029
1
Capscrew, Hex Hd., 3/8-16 x 1-1/2"
14
2500195
1
Spring, 3/8" x 7-3/4"
15
6010515
3
Spacer, 7/8" Long
16
2900473
3
Flat Washer, 3/8" USS
17
2900039
8
Lock Nut, 5/16-18 Nylon
18
6012232
1
Clutch Pulley 10.25"
19
6012233
1
Clutch Sheave 5.5"
20
6041175
1
Fan Spacer
21
2900978
4
Cap Screw, Flat Hd., #10-24 x 1/2"
22
2505380
1
Bearing, one way locking
23
2901504
1
Fender Washer, 5/16 x 1-3/4 x 1/16"
24
2900031
1
Lock Washer, 5/16" Split
25
2900217
1
Cap Screw, Hex Hd., 5/16-18 x 1-1/4"
26
2500519
1
Cooling Fan, 7"
27
2900038
4
Lock Washer, #10 Split
28
2900448
4
Machine Screw, Hex Hd., #10-32 x 1/2"
29
2900079
1
Cap Screw, Hex Hd., 3/8-16 x 2-1/4"
30
2500849
1
V-Belt, 4L-500
31
6018295
1
CC3700 DC Drive Fan Guard
32
2900048
2
Cap Screw, Hex Hd., 1/4-20 x 1-1/2"
33
2900009
6
Flat Washer, 1/4" SAE
34
2900008
2
Cap Screw, Hex Hd., 1/4-20 x 1"
35
2900010
4
Lock Nut, 1/4-20 Nylon
36
6048229
1
Key, 3/16" Sq. x 1-1/4"
