Detroit Radiant Products Company SV Series User Manual
Page 11
Factory recommended mounting heights are listed as a guideline. If infrared heaters are mounted too low
or too high, they may result in discomfort or lack of heat. Detroit Radiant Products Company generally
recommends observing the recommended mounting heights to optimize comfort conditions. However,
certain applications such as spot heating, freeze protection, outdoor patio heating or very high ceilings
may result in the heaters being mounted outside of the factory recommended mounting heights.
Tube Heater General Manual
11
Dimension C
Maximum
distance
between
heater
and wall
Chart 3.1 •
Recommended Mounting Heights and Coverages
Note: This chart is provided as a guideline. Actual conditions may dictate variation from this data.
3.0
Installation
•
Mounting Heights and Coverages
M
o
d
el
BT
U R
an
g
e
Co
ver
ag
e A
rea
S
tr
ai
g
h
t C
on
fi
g
.
(L
xW)
Co
ver
ag
e A
rea
U
-T
ub
e C
on
fi
g
.
(L
xW)
R
ecom
m
end
ed
M
oun
ting
H
eig
h
t (
ft
.)
D
ist
anc
e B
et
w
ee
n
H
ea
te
rs (
ft
.)
D
im
en
sio
n
A
D
ist
anc
e B
et
w
ee
n
H
ea
te
r R
ow
s (
ft
.)
D
im
en
sio
n
B
M
ax
im
um
D
is
ta
n
ce
B
et
w
ee
n H
ea
te
rs a
n
d
w
al
l (
ft
.)
D
im
en
sio
n
C
Figure 3.3
•
Mounting Height Dimensions (see Chart 3.1 for dimensions)
Dimension A
Dimension B
Distance between
heater rows
Dimension C
Maximum distance between heater and wall
Dimension A
Note: Dimensions A, B & C are based upon heaters hung at the factory recommended mounting height.
20 ft.
50-65 MBH
10’ - 16’
20’ x 12’
12’ x 12’
10’ - 20’
20’ - 40’
16’
75-100 MBH
12’ - 20’
22’ x 15’
N/A
20’ - 30’
30’ - 50’
18’
30 ft.
50-65 MBH
10’ - 16’
30’ x 14’
17’ x 13’
10’ - 20’
20’ - 40’
17’
75-125 MBH
12’ - 20’
33’ x 18’
18’ x 15’
20’ - 30’
30’ - 50’
20’
40 ft.
50-65 MBH
10’ - 16’
40’ x 16’
22’ x 14’
10’ - 20’
20’ - 40’
20’
75-125 MBH
12’ - 20’
44’ x 21’
23’ x 17’
20’ - 30’
30’ - 50’
20’
150-175 MBH
16’ - 30’
45’ x 26’
24’ x 20’
30’ - 40’
40’ - 60’
25’
50 ft.
100-125 MBH
15’ - 25’
55’ x 24’
28’ x 19’
20’ - 30’
30’ - 50’
25’
150-200 MBH
16’ - 30’
56’ x 30’
29’ x 23’
30’ - 40’
40’ - 60’
25’
60 ft.
125 MBH
16’ - 25’
66’ x 27’
33’ x 21’
20’ - 30’
30’ - 50’
25’
150-200 MBH
17’ - 40’
67’ x 34’
34’ x 26’
30’ - 40’
40’ - 60’
25’
70 ft.
175-200 MBH
17’ - 40’
78’ x 38’
39’ x 29’
30’ - 40’
40’ - 60’
30’
80 ft.
200 MBH
18’ - 45’
89’ x 42’
44’ x 32’
30’ - 40’
40’ - 60’
30’
