ASCII Import/Export
41
The dialog "ASCII Import Settings" will open.
Settings for ASCII import files without header:
Select the format type from one to six from the drop down menu "Format".
Select the number of the row from which the file should be imported. Row numbers are available
from one to ten from the drop down menu "From row".
Select the "Output Mode" in the check boxes: Voltage or Current.
Settings for ASCII import files with or without header:
Please choose the factor of amplification in "Amplification". This is very helpful, for example,
for importing data recorded in microvolt μV and now needed in millivolt mV. That means, the
factor is 1000 or – for higher stimulation signals - may be 10000. Please see chapter "Format
Type 6" above.
Important: MC_Stimulus II uses the header of an ASCII import file, if a header is available.
If no header is available, MC_Stimulus II applies the settings of the dialog "ASCII Import Setting".
