Programming Stimulus Protocols
19
 Enter each voltage / current level and the duration of the pulse. The voltage / current jumps
directly to the specified level. In one row, you can enter up to three voltage / current levels. Use
the next row for programming more levels.
Ramp pulse type
 Define the starting point, end point, and the length of the ramp. The ramp is then build
according to these parameters in small single steps of 20 μs.
Sine wave pulse type
 Define the amplitude and the period of the sine wave. The sine wave is then computed
according to these parameters with a minimum resolution of 1 mV and 20 μs. If you enter
a negative amplitude, the sine wave starts with its negative alternation.
