LTP-Director Manual
14
Table: Connections for TTL signals between USB-ME256 device, MEA1060-BC amplifiers
and stimulus generator STG.
Device / Connector Type Cable Device / Connector Type
STG 4008 / Sync OUT 1 BNC - Lemo USB-ME256 / Digital Trigger IN 0
STG 4008 / Sync OUT 2 BNC - BNC MEA1060-BC A / BNC
STG 4008 / Sync OUT 3 BNC - Lemo USB-ME256 / Digital Trigger IN 1
STG 4008 / Sync OUT 4 BNC - BNC MEA1060-BC B / BNC
STG 4008 / Sync OUT 5 BNC - Lemo USB-ME256 / Digital Trigger IN 2
STG 4008 / Sync OUT 6 BNC - BNC MEA1060-BC C / BNC
STG 4008 / Sync OUT 7 BNC - Lemo USB-ME256 / Digital Trigger IN 3
STG 4008 / Sync OUT 8 BNC - BNC MEA1060-BC D / BNC
4. Connect the Digital Trigger IN sockets (lemo sockets) of the USB-ME256 device to the Sync OUT
(BNC sockets) of the STG (Lemo - BNC cable). Digital Trigger IN 0 of the USB-ME256 device has
to be connected to Sync OUT 1 of the STG, Digital Trigger IN 1 to Sync OUT 3, Digital Trigger IN 2
to Sync OUT 5, and Digital Trigger IN 3 to Sync OUT 7.
5. Connect the BNC sockets of the MEA1060-BC amplifiers to the Sync OUT (BNC sockets) of the
STG (BNC - BNC cables). Please connect the BNC socket of the MEA1060-BC A amplifier to the
Sync OUT 2 of the STG, MEA B amplifier to the Sync OUT 4, MEA C to Sync OUT 6, and MEA D
to Sync OUT 8.
Table: Connections for stimulation pulses between MEA1060-BC amplifier and stimulus generator
STG for stimulating MEA electrodes on pathway 1 and 2 with LTP-Director. Please connect
additional grounding cables (2 mm plugs cable black) to the STG Stimulus GND connectors.
Device / Connector Type Cable Device / Connector Type
STG / Stimulus OUT 1 + 2 mm plugs cable blue MEA1060-BC A / Stimulus A
STG / Stimulus OUT 2 + 2 mm plugs cable red MEA1060-BC A / Stimulus B
STG / Stimulus OUT 3 + 2 mm plugs cable blue MEA1060-BC B / Stimulus A
STG / Stimulus OUT 4 + 2 mm plugs cable red MEA1060-BC B / Stimulus B
STG / Stimulus OUT 5 + 2 mm plugs cable blue MEA1060-BC C / Stimulus A
STG / Stimulus OUT 6 + 2 mm plugs cable red MEA1060-BC C / Stimulus B
STG / Stimulus OUT 7 + 2 mm plugs cable blue MEA1060-BC D / Stimulus A
STG / Stimulus OUT 8 + 2 mm plugs cable red MEA1060-BC D / Stimulus B
