IST-QUADTEK M540 LYNX

High Temperature Black and White IR
Camera Series

The IST-Quadtek M540 series of near IR Black and
White High-Temperature Cameras is designed to give
you the flexibility to customize electronics, lenses,
filters and other options to provide continuous
monitoring of your process. Able to penetrate
gaseous and fine particulate interferences, these
cameras give a considerably improved image of
furnace, boiler, ash hoppers, or other processes.
Straight, oblique, or right angle lens tube options
are available to offer more flexibility in mounting the
camera.

FEATUrES/BENEFITS

Coal Fired Utility Boilers

Excellent image quality and depth of field of the
superheater tubes in the upper boiler.

Ash Hopper

Allows the ash system operator to effectively monitor
the behavior and trends of the build-up and the flow
within the ash hopper.

Bubbling Fluidized Bed Boilers

Unique OAL lens gives plan view of bed with simple
through-wall camera installation. Helps operator to
recognize build-up of cake in the sand bed
