NGM 204S
Particulate, Gas & Iodine Monitors
PHYSICAL CHARACTERISTICS
●
Radiation detected: beta and gamma
●
Detector: dual large area silicon
●
Sampling chamber: 300 ml (300 cc)
●
Typical energy windows:
○
Beta: 80 keV to 2.5 MeV
○
Gamma: 80 keV to 2.5 MeV
●
Typical measurement range:
○
85
Kr: 3.7 10
+4
to 7.4 10
+13
Bq/m
3
(10
-6
to 2 10
+3
μCi/cc)
○
133
Xe: 3.7 10
+4
to 3.7 10
+12
Bq/m
3
(10
-6
to 10
+2
μCi/cc)
ENVIRONMENTAL CHARACTERISTICS
●
Long term temperature:
+10°C to +40°C (+50°F to +104°F)
●
Periodic
temperature:
-5°C to +55°C (+23°F to +131°F)
●
MTBF: > 20 000 hours, with preventive maintenance
●
TID: 100 Gy (10
+4
rad)
PNEUMATIC CHARACTERISTICS
●
Standard fl ow rate: 35 l/min (1.24 scfm)
●
Pressure drop: according to the fi lter dust loading
MECHANICAL CHARACTERISTICS
●
Dimensions: 1305 mm x 830 mm x 680 mm
(51.4 in x 32.7 in x 26.8 in)
●
Weight: ~ 310 kg (~ 684 lb)
●
Color: gray RAL 7030 (decontaminable paint)
●
Inlet tube connection: Ø 12 mm OD (1/2 in)
●
Outlet tube connection: Ø 12 mm OD (1/2 in)
ELECTRICAL CHARACTERISTICS
●
Power supply: refer to possible versions
●
Data link outputs: 1 RS232 and 2 isolated RS485
●
Alarm relays: 3 SPDT relays
●
I/O: 2 isolated analog outputs (0/4-20 mA)
SIGNALING (Applicable to LPDU only)
●
Alphanumeric display: measurement, status…
●
Sound alarm: buzzer 90 dBA at 1 meter
●
Visual alarm: 3 lights (red, yellow, green)
REFERENCE STANDARDS
●
Nuclear: IEC60761
●
Environmental: IEC60780, IEEE323, RG 1.97
●
Seismic: IEC60980, IEEE344
●
EMC: 2006/95/CE and 2004/108/CE, EPRI 102323,
MIL STD 461 E, IEC61000-6-2 and IEC61000-6-4
VERSIONS
●
230 Vac or 230 Vac + 400 Vac 3Ø or 120 Vac
+ 400 Vac 3Ø
●
Solenoid check sources
●
PIS sampler
●
Dust fi lter holder
●
Gas grab sampler ports
ACCESSORIES
●
Local & remote display units
●
Calibration tools
●
Software
●
USB converters
