PM 205S
Particulate, Gas & Iodine Monitors
PHYSICAL CHARACTERISTICS
●
Radiation detected: beta
●
Detector: 2’’ thin plastic scintillator + PMT +
embedded LED
●
Filter type: fi berglass 49 mm (1.9 in)
●
Lead shield: 7.5 cm/4 π (3 in/4 π)
●
Typical energy range: > 30 keV
●
Typical measurement range: 3.7 10
-2
to 3.7 10
+3
Bq/m
3
(10
-12
to 10
-7
μCi/cc)
ENVIRONMENTAL CHARACTERISTICS
●
Long term temperature: +10°C to +40°C
(+50°F to +104°F)
●
Periodic temperature (processing unit):
-5°C to +55°C (+23°F to +131°F)
●
Periodic temperature (detector):
+0°C to +60°C (+32°F to +140°F)
●
MTBF (processing unit): > 50 000 hours
●
MTBF (detector): > 20 000 hours
●
TID: 100 Gy (10
+4
rad)
●
Protection index: IP65 and IK07
PNEUMATIC CHARACTERISTICS
●
Standard fl ow rate: 28.3 l/min (1 scfm)
●
Pressure drop: 50 mbar (0.73 psi)
MECHANICAL CHARACTERISTICS
●
Dimensions: 889 mm x 1397 mm x 1651 mm
(35 in x 55 in x 65 in)
●
Weight: 700 kg (1543 lb)
●
Color: gray RAL 7030 (decontaminable paint)
●
Inlet tube connection: Ø 1 in
●
Outlet tube connection: Ø 1/2 in
ELECTRICAL CHARACTERISTICS
●
Power supply: 230 Vac – 50 Hz or 120 Vac – 60 Hz
●
Data link outputs: 1 RS232 and 2 isolated RS485
●
Alarm relays: 3 SPDT relays
●
I/O: 2 isolated analog outputs and 1 isolated analog
input (0/4-20 mA)
SIGNALING (Applicable to LPDU only)
●
Alphanumeric display: measurement, status…
●
Sound alarm: buzzer 90 dBA at 1 meter
●
Visual alarm: 3 lights (red, yellow, green)
REFERENCE STANDARDS
●
Nuclear: IEC60761-1 and IEC60761-2, IEC61172,
IEC61578
●
Environmental: IEC60780, IEEE323
●
Seismic: IEC60980, IEEE344
●
EMC: 2006/95/CE and 2004/108/CE, EPRI 102323,
MIL STD 461 E, IEC61000-6-2 and IEC61000-6-4
VERSIONS
●
230 Vac or 120 Vac
●
LPDU or LPU
●
With or without check source
●
With or without heater
●
PIS sampler
ACCESSORIES
●
Calibration tools
●
Software
●
Ethernet
●
USB converters
