RD-02 & RD-02L Intelligent Detectors
Detection & Identifi cation
20996043_RD02_02L_EN_A
TECHNICAL SPECIFICATIONS:
RD-02 Intelligent Detector RD-02L Intelligent Detector
Physical characterstics
* Background shielded
50 mm Pb + 3 mm Al
radiation detected: gamma and x-rays, according •
to ambient dose equivalent H*(10)
energy range: 50 keV - 1.3 MeV for dose rate
•
range 0.01 µSv/h - 10 mSv/h, and 80 keV - 1.3 MeV
for dose rate range 10 mSv/h - 10 Sv/h
detector type: two halogen quenched, energy
•
compensated GM tubes
dose measurement range: 0.01 µSv - 10 Sv
•
dose rate measurement range: 0.01 µSv/h - 10 •
Sv/h
calibration accuracy: ± 5% of the reading in 3
•
mSv/h Cs-137 exposure at +20 o C
energy response: ± 30% over energy range 50 keV •
- 1.3 MeV, from background to 10 mSv/h,
±30% over energy range 50 keV - 1.3 MeV,
above 10 mSv/h
±20% over energy range 80 keV - 1.3 MeV,
above 10 mSv/h
dose rate linearity: ± 15% + 1 digit over the range
•
0.10 µSv/h - 10 Sv/h
directional response: ± 15% within 180
• o horizon-
tally from the calibration direction,
± 30% within ± 45
o vertically from the calibration
direction
GM tube volumes: 7 cm3 (low dose rate) and 0.13
•
cm3 (high dose rate)
GM tube sensitivity: 200 cps (low dose rate) and 3
•
cps (high dose rate) @ 100 µSv/h
GM tube dead time: 110 µs for low dose rate and
•
13 µs for high dose rate tube
self count rate: 10 cpm for low dose rate tube and
•
1 cpm for high dose rate tube *
radiation detected: gamma and x-rays, according to •
ambient dose equivalent H*(10)
energy range: 50 keV - 1.3 MeV for dose rate range
•
0.01 µSv/h - 2 mSv/h, and 80 keV - 1.3 MeV for dose
rate range 2 mSv/h - 10 Sv/h
detector type: two halogen quenched, energy
•
compensated GM tubes
dose measurement range: 0.01 µSv - 10 Sv
•
dose rate measurement range: 0.01 µSv/h - 10 Sv/h •
calibration accuracy: ± 5% of the reading in 3 mSv/h •
Cs-137 exposure at +20 o C
energy response: ± 30% over energy range 50 keV - •
1.3 MeV, from background to 10 mSv/h,
± 30% over energy range 50 keV - 1.3 MeV,
above 10 mSv/h
±20% over energy range 80 keV - 1.3 MeV,
above 10 mSv/h
dose rate linearity: ± 15% ± 1 digit over the range
•
0.03 µSv/h - 10 Sv/h
directional response: ± 15% within ± 180
• o horizon-
tally from the calibration direction
± 30% within ± 45
• o vertically from the calibration
direction
GM tube volumes: 60 cm3 (low dose rate) and 0.13
•
cm3 (high dose rate)
GM tube sensitivity: 1400 cps (low dose rate) and 3
•
cps (high dose rate) @ 100 µSv/h
GM tube dead time: 160 µs for low dose rate and 13
•
µs for high dose rate tube
self count rate: 40 cpm for low dose rate tube and 1
•
cpm for high dose rate tube *
Electrical characterstics power requirement: 12 VDC, 10mA (at background level) •
connections: 8-pin lockable MIL-connector •
integration time: adjustable from 1 minute to 99 minutes •
memory: capacity for 864 dose rate records •
interface: RS-232 (1200- 9600 baud) •
compatible with: RADOS AAM-95 Environmental Monitoring SW •
Mechanical characterstics casing: impact resistant casing of anodized aluminum, shielded against RF-interference and NEMP •
RF resistance: Up to 1 GHz @ 100 V/m •
EMP resistance: Emax = 50 kV, rise time 10 nsec, fall time 1 µsec •
enclosure class: IP 67 (short term) •
ength: 260 mm, cylinder diameter 60 mm •
weight: 510 g •
length: 560 mm, cylinder diameter 60 mm •
weight: 990 g •
Environmental characterstics temperature range: operation -40 • o C to +70 o C,
storage -40 o C to +70 o C
temperature range: operation: -40 • o C to +70 o C,
storage: -40 o C to +70 o C
