Micromod MOD: 1731N ICN Mini-Link Users Guide User Manual
Page 8
IB-23C003
INTRODUCTION
1.3.2 1732N ICN Interface Board
The ICN Interface Board is an ICN controller card only and is used to add a second ICN to
the 1731N when the option board was not originally specified. The central processor is
the 63B09E using an 8-bit bus and a 2 mHz dual phase clock.
Catalog Number Description for 1732N
BASE NUMBER
1732N
ICN Interface Board
UNUSED
Z
Unused Character
ELECTRICAL CODE
10
General Purpose
UNUSED
0
Unused Character
FIRMWARE VERSION 01
Version 1
MODEL
A
1st design level
Sample Number
1732NZ10001A
1-4
